INTRINSIC PARAMETERS OF DRY CHOPPED MISCANTHUS FOR COLD PARTICLE DYNAMIC MODELING (TURNITIN)

Pasymi, pasymi (2024) INTRINSIC PARAMETERS OF DRY CHOPPED MISCANTHUS FOR COLD PARTICLE DYNAMIC MODELING (TURNITIN). Universitas Bung Hatta.

Text TurnitinArtikel-08_Pasymi.pdf Download (4MB)

Abstract

Miscanthus is a bioenergy crop that is very easy to cultivate. It has high volatile content with an average energy value of about 18.8 MJ/kg on a dry basis. With the benefits mentioned above, Miscanthus is potential as a fuel for the suspended furnace. Therefore, the furnace design for the Miscanthus particle needs to be developed immediately. A relatively fast and low-cost technique to develop a burner furnace design is the modeling. This study aims to determine the intrinsic parameters values of dry Miscanthus particles needed in cold particle dynamic modeling. The various reasonable experimental techniques were used to obtain these parameter’s values. Then, a series of simulations and experiments of dry chopped Miscanthus dynamic in a special burner was conducted to assess the conformity of these values. The intrinsic parameters values of dry chopped Miscanthus obtained are as follows; shape factor (fs) 0.52, true particle density (ρp) 245 kg m-3, minimum, maximum, and mean particle diameters (dp) 106, 9520, and 1384 µm respectively, and spread parameter (n) 1.22. Qualitatively, the particle dynamic simulation results, using RSM and k- models, showed similar particle pathlines to the experiment results, in terms of the frequency and intersection of the helical structure formed in the burner cylinder. It indicates that the intrinsic parameters values obtained in this study are reliable results and can be used for further simulation works. In addition, particle dynamics experiments and simulations also revealed that the particle pathline in the burner cylinder tend to move near the cylinder wall in a helical pattern; a single helix pattern in a single tangential inlet burner and a double helix pattern in a double tangential inlets burner. Regardless of the effect of the tangential inlet number, the helical pattern in the burner cylinder was also influenced by the initial swirl number (ISN) of the flow. The lower the ISN, the lower the helical frequency formed and vice versa. This study also proved that at low to moderate swirl intensities, the k-Ephsilon turbulent model can be relied upon to model particle dynamics in a cyclone burner.
